SANY Electric Semi-trailer Tractor 6x4 Zero Emission Heavy Tractor

Tel：+0086 18153459109
WhatsApp：+86 18153459109
Email：ekko@sdshantuigroup.com
Contact Us

Product Description

ModelSYG3
Host CodeKEV126158692
Basic Parameters
Drive Type6×4
Driver's Seat Location (Left/Right)Right Hand Drive
Length×Width×Height (unladen) (mm)7520×2499×3800
Wheel Base (mm)3800+1350
Front Overhang (mm)/Rear Overhang (mm)1540/830
The Fifth‑wheel50# (90# optional)
Front Distance of the Fifth‑wheel (mm)900
The Height of the Fifth‑wheel (mm)1285±20
Minimum Ground Clearance (mm)220
Front Turning Radius (mm)2150
Rear Turning Radius (mm)2050
Curb Weight (kg)13300
Technically Permissible Gross Combination Weight (kg)50000 Single Trailer /80000 Double Trailers
Frame Parameter
Section Height×Section Width×Frame Thickness (mm)300×80×(8+5)
Driving Motor
TypeHigh Performance Centre Drive Motor
Rated Power(kW)/Rotation Speed(r/min)/Torque(N‑m)330/2300/1370
Peak Power(kW)/Rotation Speed(r/min)/Torque(N‑m)480/3500/2800
Power Battery
Battery Capacity (kWh)588kWh
Energy Supply Method600A Dual‑gun DC Fast‑charging/5min Swapping
Charging StandardEuropean Standard CCS2/Chinese Standard GB/T
Charging Time20%‑80%≤60min (600A Dual‑gun)
Transmission
Type6‑speed AMT + Column Shifter
Number of Gears6
Power Take‑offQH50
Vehicle Control Unit
TypeSelf‑developed VCU
Axle
Front Load Capacity (tons)7.5t ( 295/80R22.5); 8t (385/65R22.5)
Middle/Rear Load Capacity (tons)11.5t/11.5t (11R22.5)
Middle/Rear Ratio5.92
Tyres
Type

Front: 295/80R22.5 Rear: 11R22.5

Front: 385/65R22.5 Rear: 11R22.5

Rim
TypeFront Steel/Rear Aluminum
Suspension
Front /RearFront 3 Leaf Spring/Rear 8 Airbag Suspension
Braking System
TypeAEBS+ESC+Braking Energy Regeneration Function
Trailer Electrical Interface7pin
Trailer Power Supply24V
