3 Axle Lowboy Semi-Trailer / New / Refurbished Lowboy Semi-Trailer

Product Description

Item	Specification
Trailer Model	3 Axle Lowboy Semi-Trailer
Overall Dimension(Lx W x H)(mm)	1300025001650mm
Working size(LxWxH)	900025001300mm
Loading Weight( KG)	60000
Axle Brand	13TON Fuwa axles brand
Axle Number	3
Wheelbase(mm)	8580+1310+1310
Leaf spring	90(W)mm13(Thick)mm10 Layer
Side beam	Q235 20# channel steel
Platform plate	4mm Diamond plate
Tire Type and quantity	11.00R20 12units
Spare Wheel Bracket	1 pieces
Rim	9.00‑22.5
Traction Pin	2" or 3.5"
Landing Gear	Chinese standard 28ton
Brake air chamber	Two double and two single chamber
Electrical system	1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)Tail lamp with turn signal, brake light & reflector, side lamp etc.One set 6‑core standard Cable.
