Heavy Duty Rear Dump Semi Trailer Back Dump Tipper Truck with Big Volume / New / Refurbished Dump Semi-Trailer

Product Description

Tare weight	9.8ton
Dimension	950025003850mm outside 880023501700mm work space
Color	Customized
Axle	2/3/4 axle FUWA brand optional 13T-16T
Side wall thickness	3-6mm Q345B steel
Bottom plate thickness	5-8mm Q345B steel
Lifting system	Full set of HYVA (FC214-5-07130) Hydraulic Lifting Cylinder
Tire	11.00R20/12.00R20/11R22.5/12R22.5 optional
Main beams	Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic Submerged-Arc processes.Upper plate: 16mm; middle plate: 8mm; bottom plate: 18mmHeight: 500mm, material Q345B steel
Wheel rim	8.5-20/9.0-20/8.25-22.5/9.0-22.5/9.75 optional
Suspension	Mechanical suspension or air suspension
Leaf spring	10 pcs 9013mm
Floor	8mm plate, side wall 6mm
Kingpin	JOST 2"/3.5" bolt-in king pin
Landing gear	JOST two-speed, manual operating, heavy duty landing gear
Cylinder	HYVA
Braking system	WABCO RE6 relay valve, T30/30 spring brake chamber; 40L air tanks
ABS	optional
Painting	Complete chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box
Delivery detail	By bulk cargo or ro-ro, the trailer size can be customized, the tractor truck can choose 6*4 model
