1.5 Ton Fully Hydraulic Roller

Product Description

Action		Engine
Speed	0~8km/h	Model	CHANGCAI 192FA
Turning radius	2100mm	Type	Diesel
Gradeability	30%	Power	11HP,3600rpm
Compaction		Fuel tank capacity	5.5L
Static line load before/after	83/72N/cm	Fuel consumption	300g/km.h
Nominal amplitude	0.5mm	Dimensions
Vibration frequency	75Hz	Drum wheel width (front, rear)	800mm
Violent force	30kN	Drum wheel diameter (front, rear)	530mm
Working		Length	2200mm
Drive form	Hydraulic two-wheel drive	Width	920mm
Vibration form	hydraulic vibration	Height	1620mm
	Front wheel vibration	Packaging size	230010001650mm
